INJORA IR80-30 Pickup Hard Body for 1/30 SCX30 Bronco JLU K10

INJORA IR80-30 Pickup Hard Body for 1/30 Axial SCX30, 99mm Wheelbase

Note:

• Compatible with 99mm wheelbase SCX30 Bronco, JLU and K10.
• Compatible with INJORA SCX30 chassis.
• Not compatible with the 107mm wheelbase SCX30 Tacoma.
• Due to the pickup bed design, some adjustment to the electronics layout may be needed for proper fitment.
• Check the body mount magnet polarity before gluing. Make sure they attract, not repel.

Features:

• ABS hard body with classic pickup styling
• Rich scale details, including bumpers, light lenses, wipers, and molded body lines
• Painted versions feature a refined metallic flake finish
• Flexible rubber side mirrors help reduce damage during crawling and rollovers
• Magnetic body mounts provide a secure fit and quick body removal
• Includes a detailed scale sticker sheet

Specifications:

• Part Number: IR80-30
• Body Material: ABS
• Color: Unpainted / Gray / Purple / Green
• Dimensions (L×W×H): 141×59×40mm
• Wheelbase: 99mm
• Weight: 29g

Recommended Tires: 0.7" tires with an outer diameter of 37mm or smaller.

Installation Tip: SCX30 uses very small hardware. Use the correct-size driver and light pressure. Tighten only until the screw is seated and snug, then stop. If you feel resistance before it is seated, or if the screw does not thread smoothly, stop and check the alignment before continuing.

Package List:

• 1 × Body Kit
• 1 × Magnetic Mount Set
• 1 × Sticker Sheet
• 1 × Manual
